Treatment Advances for Glioblastoma: Tumor Markers and Targeted Treatments

Although malignant brain tumors affect thousands of persons each year, treatment has not significantly advanced. For 3 decades, the standard of care was palliative surgery, radiation, and chemotherapy. Of these, radiotherapy was the only proven way to lengthen survival time. However, since 2005 the standard of treatment has changed thanks to studies showing posi- tive results from daily temozolo- mide (Temodar) combined with radiotherapy.

Glioblastoma multiforme (GBM) is a devastatingdisease. Effective treatments are limited,and patient prognosis is poor. Most patientsrapidly become debilitated. Median survivaltime is only 1 year.

Although malignant brain tumors affect thousands of persons each year, treatment has not significantly advanced. For 3 decades, the standard of care was palliative surgery, radiation, and chemotherapy. Of these, radiotherapy was the only proven way to lengthen survival time.1 However, since 2005 the standard of treatment has changed thanks to studies showing positive results from daily temozolomide (Temodar) combined with radiotherapy.2-4

A phase 3 trial by Stupp and colleagues2 compared radiotherapy alone with radiation and concurrent daily temozolomide in patients with newly diagnosed GBM (both treatment groups received adjuvant temozolomide after completing the primary treatment regimen). Median survival for patients receiving radiotherapy plus temozolomide was 14.6 months compared with 12.1 months for patients receiving radiotherapy alone. This study, and another that looked at quality of life,3 showed that patients who received temozolomide in conjunction with radiotherapy had longer progression-free survival (PFS) and overall survival (OS) and had no decrease in quality of life compared with patients who received radiotherapy alone.

Response to temozolomide also might have a genetic basis. In conjunction with Stupp's work, Hegi and colleagues4 performed genetic testing showing that patients in whom the O6-methylguanine-DNA methyltransferase [MGMT] DNA repair gene is silenced via a methylation promoter respond better to temozolomide than patients who do not have this genetic pattern.

PROGNOSTIC FACTORS

Survival rates since the 1980s have remained steady at 12 and 15 months. The 4 key prognostic factors include age, tumor grade, Karnofsky Performance Status, and the extent of tumor resection.

Age is the strongest prognostic indicator. Because advanced age is associated with loss of thymic CD8+ T cells, age-dependent decline in immune function may explain why age has such an important influence on patients with GBM.5

HALLMARKS OF GBM

Hanahan and Weinberg6 outlined the 6 hallmarks of cancer: self-sufficiency in growth signals, evading apoptosis, insensitivity to anti-growth signals, sustained angiogenesis, limitless replicating potential, and tissue invasion with metastasis. Although researchers find these characteristics helpful for the laboratory investigation of cancer biology, they are not that useful to clinicians. However, these 6 laboratory-based cancer hallmarks can be reduced to 3 characteristics pertinent to clinicians: growth/proliferation, invasion, and angiogenesis, which are physiological characteristics of GBM7 and make this malignancy particularly deadly and resistant to treatment.

Growth/proliferation. The rapid growth of gliomas is probably caused by a cascade of activity at the genetic level originating from tyrosine kinases, such as epidermal growth factor and platelet- derived growth factor receptors7; however, additional genetic alterations leading to uncontrolled proliferation are common.8,9 Drugs that inhibit these tyrosine kinases or their downstream targets could destroy GBM with minimal non-specific systemic toxicity.

Invasion. The aggressiveness of GBM also is characterized by the tumor's invasion into surrounding white matter. Although a sharply delineated enhancement of the tumor is seen on MRI, suggesting a discrete lesion, these masses often diffusely infiltrate the brain at the microscopic level.

The mechanism for this invasive process is unclear; but matrix metalloproteinases (MMPs)- either secreted MMP-2 and MMP-910-12 or membrane-bound MT1-MMP12,13-may initiate extracellular matrix remodeling and cut a path for GBM cells.14

Furthermore, recent experimental data suggest that macrophages play an important role in tumor migration leading to tumor invasion and metastasis.15 In fact, soluble factors made by microglia can promote glioblastoma cell invasion, and this effect can be blocked by cyclosporin A.16

Angiogenesis. Angiogenesis is the third characteristic, which occurs in all tumors, including gliomas. During this process, endothelial cells from adjacent vasculature and circulating endothelial progenitors from bone marrow cooperate to create tumor microvessels.17-20 These tumor-induced microvessels have high permeability, permitting the leakage of gadolinium into the interstitial space during MRI. More important, the high permeability of these blood vessels leads to elevated interstitial pressure, which secondarily prevents adequate delivery of oxygen for radiotherapy to work and for chemotherapy to kill tumor cells.21

TUMOR MARKERS

The diagnosis of GBM is still based on tumor histology, but emerging molecular diagnostics of key genetic and epigenetic changes is becoming an important part of GBM subclassification. Currently, the 2000 World Health Organization classification of tumors is widely used in clinical practice. It classifies astrocytic malignant gliomas into grade 3 anaplastic astrocytomas characterized by nuclear polymorphism and mitoses, and grade 4 GBM as having additional features of vascular proliferation and necrosis. Furthermore, advances in neuroimaging technologies, such as vascular MRI and 39-18fluoro-39-deoxy-l-thymidine positron emission tomography ([18F]FLT PET), have improved neuro-oncologists' ability to measure tumor angiogenesis and metabolism. For identifying markers of tumor physiology, these functional neuroimaging tools are indispensable in the evaluation of targeted therapies.

Although the current histological grading system has provided valuable prognostic information and is used in clinical trials, molecular genetics may offer a more precise subclassification of GBM. For example, O6 MGMT is a DNA repair protein that varies in different persons. The methylation status of the MGMT promoter is indicative of the transcriptional activity of the gene in tumor cells, and therefore is a measure of the DNA repair potential.22

At the molecular level, treatment with temozolomide results in the formation of N7 and O6 methylguanine and O3 methyladenine DNA adducts.23 The MGMT gene encodes a DNA repair protein that removes alkyl groups from the O6 position of guanine (Figure).24 Thus, tumors with a high expression of MGMT are associated with resistance to treatment with alkylating agents. In contrast, the inactivation, or "silencing," of the MGMT gene by promoter methylation stops DNA repair and has been associated with prolonged survival in GBM patients. Furthermore, GBM could be further subclassified into primary and secondary GBM based on molecular features.

Primary GBM is a highly infiltrative tumor in elderly patients. Overexpression of epidermal growth factor receptor is common.7,25 In contrast, secondary GBM starts out as a low-grade glioma in young patients. It later transforms into GBM. The molecular changes are different and include overexpression of platelet-derived growth factor receptors at the initial stages and p53 mutations by the time tumors have become GBM.7,25

Of note is that gene profiling can identify molecular subtypes of GBM that correlate more accurately with patient survival than with traditional histology-based classifications.8,9 Also, although tumors may be histologically identical to one another, their molecular differences can have a profound effect on treatment response.7

Vascular MRI is an important tool for monitoring GBM. In identifying tumor markers, vascular MRI can provide important information on tumor microvessel physiology, providing parameters such as blood flow, permeability (often expressed as a constant Ktrans), diffusion, regional cerebral blood flow, mean transit time, and vessel diameter. These characteristics are indispensable for the evaluation of the effectiveness of antiangiogenic drugs and other targeted therapies.

For example, AZD2171 has been shown to decrease vascular permeability and support the concept of vascular normalization by pruning abnormal GBM vasculatures.21,26 The result is resolution of gadolinium enhancement and fluid-attenuated inversion recovery signals, suggesting decreased permeability and interstitial edema, respectively. Similarly, when bevacizumab (Avastin) was given to patients with radiation necrosis, a decrease in contrast enhancement was seen, suggesting an improvement in vascular permeability.27

Metabolic imaging using 18F-fluorodeoxyglucose ([18F]FDG) PET has been problematic in the past because of the low signal- to-noise ratio (SNR).28,29 However, [18F]FLT PET has better sensitivity and specificity for primary brain tumors than [18F]FDG PET. The poor SNR in traditional [18F]FDG PET is caused by high background [18F]FDG signaling, because the normal brain also takes up a relatively large amount of glucose.30 But elevated levels of thymidine are only found in cells that are actively dividing. Because normal brain tissue has low proliferative potential, the increase in [18F]FLT signaling would come primarily from dividing tumor cells.

Currently, [18F]FLT PET is an investigational procedure, but it holds promise for detecting the infiltrating edge of GBM, particularly in areas without blood-brain barrier breakdown. This type of functional tumor localization could aid in biopsy or surgical resection of GBM, as well as radiotherapy planning.

NONSPECIFIC CYTOXIC CHEMOTHERAPIES

Temozolomide is an orally administered cytotoxic agent that was approved by the FDA for the treatment of recurrent anaplastic astrocytoma in 1999,31 and for the treatment of newly diagnosed GBM in adult patients in 2005.2 This drug crosslinks the DNA of cancer cells so that they can no longer replicate.

Temozolomide is quickly absorbed after oral intake. One third of it readily crosses into the blood-brain barrier.32 In addition to the conventional schedule of 5 days of temozolomide at 150 mg/m2/d in 28-day cycles, clinical investigators have explored other dose- intensified schedules, including 7 days of temozolomide at 150 to 200 mg/m2/d in 14-day cycles33,34 and 21 days of temozolomide at 75 mg/m2/d in 28-day cycles.35

The dose-intensified schedules may be more effective than the conventional one but pose a risk of more opportunistic infections.36 However, a phase 3 study comparing various schedules of temozolomide for GBM is unavailable.

Other cytotoxic chemotherapy options for patients with GBM include irinotecan (Camptosar),37,38 combination procarbazine (Matulane), lomustine, and vincristine,39 or carmustine alone.40 The response rate is typically 15% or less. As a result, benchmark data derived from minimally effective traditional cytotoxic chemotherapies-such as 15% PFS at 6 months, 8% PFS at 1 year, 21% OS at 1 year, 6% complete response and partial response, and 33% complete response and partial response and stable disease-are typically used for comparison of new drugs for recurrent GBM in phase 2 trials.41

ANTIANGIOGENIC THERAPY

Brem and colleagues42 first described the unique properties of tumor endothelium, consisting of microvessel proliferation, endothelial cell hyperplasia, and endothelial cell mitoses. Over the years, understanding these 3 major characteristics of tumor angiogenesis has aided the development of antiangiogenic therapies. First, microvessel density provides a quantitative measure of tumor angiogenesis.42,43 Second, low-dose daily non-tumoricidal chemotherapy, or metronomic chemotherapy, has been demonstrated to have an antiangiogenic effect in laboratory settings.44-46

Metronomic temozolomide also has shown antitumor activity in animal models where it reduced angiogenesis.47 Lastly, the recent demonstration that neuroblastoma cells with MYCN oncogene amplification incorporate into tumor microvessels suggests that there are mechanisms that lead to endothelial cell hyperplasia and limit the effectiveness of single-agent antiangiogenic treatment.48 Therefore, new therapies targeting both endothelial precursors and tumor-derived endothelial cells in the tumor microvessels may be necessary.

Emerging evidence suggests that antiangiogenic treatment may be effective for GBM, particularly when combined with cytotoxic chemotherapy. The antiangiogenic effect can be achieved with monoclonal antibodies, such as bevacizumab, directed against circulating vascular endothelial growth factor (VEGF), or small molecule tyrosine kinase inhibitors, such as AZD2171, directed against VEGF receptors.

Vredenburgh and colleagues49 demonstrated encouraging results in a phase 2 study using bevacizumab and irinotecan. They noted a 61% response rate and a 30% 6-month PFS. Batchelor and colleagues26 used AZD2171 in patients with recurrent GBM and noted improvement in vascular permeability and edema on MRI in some. Both studies suggest that anti-angiogenic treatment may normalize tumor vasculature and allow improved delivery of cytotoxic chemotherapy to GBM. The adverse effects of anti-VEGF treatment include hypertension, thrombosis, and rare reversible posterior leukoencephalopathy syndrome.49,50

ANTI-INVASION THERAPY

Unfortunately, past trials using targeted anti-invasion treatments for GBM have been disappointing. For example, marimastat51 and prinomastat52 in combination with temozolomide did not improve patient survival, and the effect of major toxicity was joint pain. This is an area that needs much further research and major improvements in clinical approaches.

Acknowledgment
We thank Deborha Cooper for her help with the graphics and other technical issues.

References:

REFERENCES


1.

Salazar OM, Rubin P, Feldstein ML, Pizzutiello R. High dose radiation therapy in the treatment of malignant gliomas: final report.

Int J Radiat Oncol Biol Phys.

1979;5:1733-1740.

2.

Stupp R, Mason WP, van den Bent MJ, et al. Radiotherapy plus concomitant and adjuvant temozolomide for glioblastoma.

N Engl J Med.

2005; 352:987-996.

3.

Taphoorn MJ, Stupp R, Coens C, et al. Health-related quality of life in patients with glioblastoma: a randomised controlled trial.

Lancet Oncol.

2005;6:937-944.

4.

Hegi ME, Diserens AC, Gorlia T, et al. MGMT gene silencing and benefit from temozolomide in glioblastoma.

N Engl J Med.

2005;352:997-1003.

5.

Wheeler CJ, Black KL, Liu G, et al. Thymic CD8+ T cell production strongly influences tumor antigen recognition and age-dependent glioma mortality.

J Immunol.

2003;171:4927-4933.

6.

Hanahan D, Weinberg RA. The hallmarks of cancer.

Cell.

2000;100:57-70.

7.

Louis DN, Holland EC, Cairncross JG. Glioma classification: a molecular reappraisal.

Am J Pathol.

2001;159:779-786.

8.

Liang Y, Diehn M, Watson N, et al. Gene expression profiling reveals molecularly and clinically distinct subtypes of glioblastoma multiforme.

Proc Natl Acad Sci U S A.

2005;102:5814-5819.

9.

Nutt CL, Mani DR, Betensky RA, et al. Gene expression-based classification of malignant gliomas correlates better with survival than histological classification.

Cancer Res.

2003;63:1602-1607.

10.

Choe G, Park JK, Jouben-Steele L, et al. Active matrix metalloproteinase 9 expression is associated with primary glioblastoma subtype.

Clin Cancer Res.

2002;8:2894-2901.

11.

Friedberg MH, Glantz MJ, Klempner MS, et al. Specific matrix metalloproteinase profiles in the cerebrospinal fluid correlated with the presence of malignant astrocytomas, brain metastases, and carcinomatous meningitis.

Cancer.

1998;82: 923-930.

12.

Yamamoto M, Mohanam S, Sawaya R, et al. Differential expression of membrane-type matrix metalloproteinase and its correlation with gelatinase A activation in human malignant brain tumors in vivo and in vitro.

Cancer Res.

1996;56:384-392.

13.

Beliën ATJ, Paganetti PA, Schwab ME. Membrane-type 1 matrix metalloproteinase (MT1-MMP) enables invasive migration of glioma cells in central nervous system white matter.

J Cell Biol.

1999;144:373-384.

14.

Egeblad M, Wer Z. New functions for the matrix metalloproteinases in cancer progression.

Nat Rev Cancer.

2002;2:161-174.

15.

Condeelis J, Pollard JW. Macrophages: obli-gate partners for tumor cell migration, invasion, and metastasis.

Cell.

2006;124:263-266.

16.

Sliwa M, Markovic D, Gabrusiewicz K, et al. The invasion promoting effect of microglia on glioblastoma cells is inhibited by cyclosporine A.

Brain.

2007;130:476-489.

17.

Lyden D, Hattori K, Dias S, et al. Impaired recruitment of bone-marrow-derived endothelial and hematopoietic precursor cell blocks tumor angiogenesis and growth.

Nat Med.

2001;7:1194-1201.

18.

Rafii S, Lyden D, Benezra R, et al. Vascular and haematopoietic stem cells: novel targets for anti-angiogenesis therapy?

Nat Rev Cancer.

2002; 2:826-835.

19.

Mancuso P, Burlini A, Pruneri G, et al. Resting and activated endothelial cells are increased in the peripheral blood of cancer patients.

Blood.

2001;97:3658-3661.

20.

Folkman J. Incipient angiogenesis.

J Natl Cancer Inst.

2000;92:94-95.

21.

Jain RK. Normalizing of the tumor vasculature: an emerging concept in anti-angiogenic therapy of cancer.

Science.

2005;307:58-62.

22.

Esteller M, Hamilton SR, Burger PC, et al. Inactivation of the DNA repair gene

O

6

-methylguanine-DNA methyltransferase by promoter hypermethylation is a common event in primary human neoplasia.

Cancer Res.

1999;59:793-797.

23.

Denny BJ, Wheelhouse RT, Stevens MFG, et al. NMR and molecular modeling investigation of the mechanism of activation of the antitumor drug temozolomide and its interaction with DNA.

Biochemistry.

1994;33:9045-9051.

24.

Liu L, Gerson SL. Targeted modulation of MGMT: clinical implications.

Clin Cancer Res.

2006;12:328-331.

25.

Wantanabe K, Tachibana O, Sato K, et al. Overexpression of the EGF receptor and p53 mutations are mutually exclusive in the evolution of primary and secondary glioblastomas.

Brain Pathol.

1996;6:217-224.

26.

Batchelor TT, Sorensen AG, di Tomaso E, et al. AZD2171, a pan-VEGF receptor tyrosine kinase inhibitor, normalizes the tumor vasculature and alleviates edema in glioblastoma patients.

Cancer Cell.

2007;11:83-95.

27.

Gonzalez J, Kumar AJ, Conrad CA, Levin VA. Effect of bevacizumab on radiation necrosis of the brain.

Int J Radiat Oncol Biol Phys.

2007;67:323-326.

28.

Ricci PE, Karis JP, Heiserman JE, et al. Differentiating recurrent tumor from radiation necrosis: time for re-evaluation of positron emission tomography?

AJNR.

1998;19:407-413.

29.

Olivero WC, Dulebohn SC, Lister JR. The use of PET in evaluating patients with primary brain tumours: is it useful?

J Neurol Neurosurg Psychiatry.

1995;58:250-252.

30.

Chen W, Cloughesy T, Kamdar N, et al. Imaging proliferation in brain tumors with 18F-FLT PET: comparison with 18F-FDG.

J Nucl Med.

2005; 46:945-952.

31.

Yung WKA, Prados MD, Yaya-Tur R, et al. Multicenter phase II trial of temozolomide in patients with anaplastic astrocytoma or anaplastic oligoastrocytoma at first relapse.

J Clin Oncol.

1999;17:2762-2771.

32.

Cohen MH, Johnson JR., Pazdur R. Food and drug administration drug approval summary: temozolomide plus radiation therapy for the treatment of newly diagnosed glioblastoma multiforme.

Clin Cancer Res.

2005;11:6767-6771.

33.

Wick W, Steinbach JP, Küker WM, et al. One week on/one week off: a novel active regimen of temozolomide for recurrent glioblastoma.

Neurology.

2004;62:2113-2115.

34.

Vera K, Djafari L, Faivre S, et al. Dose-dense regimen of temozolomide given every other week in patients with primary central nervous system tumors.

Ann Oncol.

2004;15:161-171.

35.

Tosoni A, Cavallo G, Ermani M, et al. Is protracted low-dose temozolomide feasible in glioma patients?

Neurology.

2006;66:427-429.

36.

Wong ET. Correspondence: is protracted low-dose temozolomide feasible in glioma patients?

Neurology.

2006;67:543-544.

37.

Friedman HS, Petros WP, Friedman AH, et al. Irinotecan therapy in adults with recurrent or progressive malignant glioma.

J Clin Oncol.

1999; 17:1516-1525.

38.

Buckner JC, Reid JM, Wright K, et al. Irinotecan in the treatment of glioma patients: current and future studies of the North Central Cancer Treatment Group.

Cancer.

2003;97:2352-2358.

39.

Schmidt F, Fischer J, Herrlinger U, et al. PCV chemotherapy for recurrent glioblastoma.

Neurology.

2006;66:587-589.

40.

DeAngelis LM, Burger PC, Green SB, Cairncross JG. Malignant glioma: who benefits from adjuvant chemotherapy?

Ann Neurol.

1998;44:691-695.

41.

Wong ET, Hess KR, Gleason MJ, et al. Outcomes and prognostic factors in recurrent glioma patients enrolled onto phase II clinical trials.

J Clin Oncol.

1999;17:2572-2578.

42.

Brem S, Cotran R, Folkman J. Tumor angiogenesis: a quantitative method for histologic grading.

J Natl Cancer Inst.

1972;48:347-356.

43.

Leon SP, Folkerth RD, Black PM. Microvessel density is a prognostic indicator for patients with astroglial brain tumors.

Cancer.

1996;77:362-372.

44.

Kerbel RS, Kamen BA. The anti-angiogenesis basis of metronomic chemotherapy.

Nat Rev Cancer.

2004;4:423-436.

45.

Man S, Bocci G, Francia G, et al. Antitumor effects in mice of low-dose (metronomic) cy- clophosphamide administered continuously through the drinking water.

Cancer Res.

2002;62: 2731-2735.

46.

Vacca A, Lurlaro M, Ribatti D, et al. Antiangiogenesis is produced by nontoxic doses of vinblastine.

Blood.

1999;94:4143-4155.

47.

Kim JT, Kim JS, Ko KW, et al. Metronomic treatment of temozolomide inhibits tumor cell growth through reduction of angiogenesis and augmentation of apoptosis in orthotopic models of gliomas.

Oncol Rep.

2006;16:33-39.

48.

Pezzolo A, Parodi F, Corrias MV, et al. Tumor origin of endothelial cells in human neuroblastoma.

J Clin Oncol.

2007;25:376-383.

49.

Vredenburgh JJ, Desjardins A, Herndon JE, et al. Phase II trial of bevacizumab and irinotecan in recurrent malignant glioma.

Clin Cancer Res.

2007;13:1253-1259.

50.

Glusker P, Recht L, Lane B. Reversible posterior leukoencephalopathy syndrome and bevacizumab.

N Engl J Med.

2006;354:980-981.

51.

Groves MD, Puduvalli VK, Hess KR, et al. Phase II trial of temozolomide plus the matrix metalloproteinase inhibitor, marimastat, in recurrent and progressive glioblastoma multiforme.

J Clin Oncol.

2002;20:1383-1388.

52.

Levin V, Phuphanich S, Glantz MJ, et al. Randomized phase II study of temozolomide (TMZ) with and without the matrix metalloproteinase (MMP) inhibitor prinomastat in patients (pts) with glioblastoma multiforme (GBM) following best surgery and radiation therapy.

Proceed ASCO.

2002;21:26a.
